Các addon cài trong hass yêu cầu cần có
* Bubble Card
* Bar card
Code để card
type: grid
cards:
- type: heading
heading: Pack 130Ah
heading_style: title
- type: custom:bubble-card
card_type: button
sub_button:
- entity: switch.jk_130_charging
name: Sạc
show_name: false
show_background: true
show_state: true
show_last_changed: false
show_attribute: false
icon: mdi:battery-charging-high
tap_action:
action: toggle
double_tap_action:
action: toggle
hold_action:
action: toggle
- entity: switch.jk_130_discharging
name: Xả
show_state: true
show_name: false
show_last_changed: false
icon: mdi:battery-minus-outline
tap_action:
action: toggle
- entity: switch.jk_130_balancer
show_name: true
name: Cân Bằng
tap_action:
action: toggle
entity: switch.jk_130_enable_bluetooth_connection
show_name: false
show_last_changed: false
show_attribute: false
show_state: true
card_layout: large
styles: ""
tap_action:
action: none
- type: vertical-stack
cards:
- type: custom:stack-in-card
keep:
margin: false
box_shadow: false
background: false
cards:
- type: grid
square: false
columns: 2
cards:
- type: markdown
content: >-
<center><b><font color=#bda442 size=6>{{
states('sensor.jk_130_total_voltage') }} V</font></b><br>
C.Suất: <font color=#bda442>{{
states('sensor.jk_130_power') }} W</font><br>
D.Lượng: <font color=#bda442>{{
states('sensor.jk_130_total_battery_capacity_setting') }}
Ah</font><br> Xả: <font color=#bda442>{{
states('sensor.jk_130_total_charging_cycle_capacity') }}
Ah</font><br> Áp TB.: <font color=#bda442>{{
states('sensor.jk_130_average_cell_voltage') }} V</font><br>
Cân bằng: <font color=#bda442>{{
states('sensor.jk_130_balancing_current') }} A</font><br>
- type: markdown
content: >-
<center><b><font color=#bda442 size=6>{{
states('sensor.jk_130_current') }} A</font></b><br>
SOC: <font color=#bda442>{{
states('sensor.jk_130_state_of_charge') }} %</font><br>
Còn: <font color=#bda442>{{
states('sensor.jk_130_capacity_remaining') }} Ah</font><br>
Chu kỳ: <font color=#bda442>{{
states('sensor.jk_130_charging_cycles') }}</font><br> Lệch
Cell.: <font color=#bda442>{{
states('sensor.jk_130_delta_cell_voltage') }} V</font><br>
Nhiệt MOS.: <font color=#bda442>{{
states('sensor.jk_130_power_tube_temperature') }}
°C</font><br> Nhiệt T1: <font color=#bda442>{{
states('sensor.jk_130_temperature_sensor_1') }} °C</font><br>
Nhiệt T2: <font color=#bda442>{{
states('sensor.jk_130_temperature_sensor_2') }} °C</font><br>
card_mod:
style: |
ha-card {
backdrop-filter: blur(10px);
box-shadow: none;
border: none
}
- type: horizontal-stack
cards:
- type: custom:bar-card
direction: up
columns: 8
decimal: 3
max: 3.45
min: 3
height: 80px
severity:
- color: darkred
from: 3.45
to: 4
- color: darkorange
from: 3.4
to: 3.45
- color: rgb(189, 164, 66)
from: 3.1
to: 3.4
- color: darkred
from: 2.5
to: 3.1
positions:
icon: "off"
indicator: inside
name: inside
entities:
- entity: sensor.jk_130_cell_voltage_1
name: Cell 01
- entity: sensor.jk_130_cell_voltage_2
name: Cell 02
- entity: sensor.jk_130_cell_voltage_3
name: Cell 03
- entity: sensor.jk_130_cell_voltage_4
name: Cell 04
- entity: sensor.jk_130_cell_voltage_5
name: Cell 05
- entity: sensor.jk_130_cell_voltage_6
name: Cell 06
- entity: sensor.jk_130_cell_voltage_7
name: Cell 07
- entity: sensor.jk_130_cell_voltage_8
name: Cell 08
- entity: sensor.jk_130_cell_voltage_9
name: Cell 09
- entity: sensor.jk_130_cell_voltage_10
name: Cell 10
- entity: sensor.jk_130_cell_voltage_11
name: Cell 11
- entity: sensor.jk_130_cell_voltage_12
name: Cell 12
- entity: sensor.jk_130_cell_voltage_13
name: Cell 13
- entity: sensor.jk_130_cell_voltage_14
name: Cell 14
- entity: sensor.jk_130_cell_voltage_15
name: Cell 15
card_mod:
style: |-
bar-card-value {
margin-right: auto;
margin-left: auto;
margin-bottom: 15px;
font-size: 10px;
font-weight: normal;
}
bar-card-name {
margin-right: auto;
margin-left: auto;
margin-bottom: 0px;
font-size: 7px;
font-weight: normal;
}
- type: custom:stack-in-card
keep:
margin: false
box_shadow: false
background: false
cards:
- type: grid
square: false
columns: 2
cards:
- type: markdown
content: >-
<center>01. {% if
states('sensor.jk_130_max_voltage_cell') == '1' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_1') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'1' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_1') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_1') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_1') }} Ω <br>
02. {% if
states('sensor.jk_130_max_voltage_cell') == '2' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_2') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'2' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_2') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_2') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_2') }} Ω <br>
03. {% if
states('sensor.jk_130_max_voltage_cell') == '3' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_3') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'3' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_3') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_3') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_3') }} Ω <br>
04. {% if
states('sensor.jk_130_max_voltage_cell') == '4' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_4') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'4' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_4') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_4') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_4') }} Ω <br>
05. {% if
states('sensor.jk_130_max_voltage_cell') == '5' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_5') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'5' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_5') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_5') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_5') }} Ω <br>
06. {% if
states('sensor.jk_130_max_voltage_cell') == '6' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_6') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'6' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_6') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_6') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_6') }} Ω <br>
07. {% if
states('sensor.jk_130_max_voltage_cell') == '7' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_7') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'7' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_7') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_7') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_7') }} Ω <br>
08. {% if
states('sensor.jk_130_max_voltage_cell') == '8' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_8') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'8' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_8') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_8') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_8') }} Ω <br></center>
- type: markdown
content: >-
<center>09. {% if
states('sensor.jk_130_max_voltage_cell') == '9' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_9') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'9' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_9') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_9') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_9') }} Ω <br>
10. {% if
states('sensor.jk_130_max_voltage_cell') == '10' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_10') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'10' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_10') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_10') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_10') }} Ω <br>
11. {% if
states('sensor.jk_130_max_voltage_cell') == '11' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_11') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'11' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_11') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_11') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_11') }} Ω <br>
12. {% if
states('sensor.jk_130_max_voltage_cell') == '12' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_12') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'12' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_12') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_12') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_12') }} Ω <br>
13. {% if
states('sensor.jk_130_max_voltage_cell') == '13' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_13') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'13' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_13') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_13') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_13') }} Ω <br>
14. {% if
states('sensor.jk_130_max_voltage_cell') == '14' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_14') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'14' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_14') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_14') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_14') }} Ω <br>
15. {% if
states('sensor.jk_130_max_voltage_cell') == '15' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_15') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'15' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_15') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_15') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_15') }} Ω <br>
16. {% if
states('sensor.jk_130_max_voltage_cell') == '16' %} <font
color="#3090C7">{{ states('sensor.jk_130_cell_voltage_16') }}
V</font> {% elif states('sensor.jk_130_min_voltage_cell') ==
'16' %} <font color="red">{{
states('sensor.jk_130_cell_voltage_16') }} V</font> {% else %}
{{ states('sensor.jk_130_cell_voltage_16') }} V {% endif %}
/ {{
states('sensor.jk_130_cell_resistance_16') }} Ω <br></center>
